Software updates for the 2011 FRC Season are now located on the FIRSTForge WPILib project server. To access the content you don't need a FIRSTForge account. You do not need WPILib project membership - please don't request it. The software is located in 3 areas:

• File Releases - update for C++ and Java
• Documents - all documentation
• Wiki - an FAQ covering issues related to C++ and Java

and you can access the Project Home with news and other information.

Wind River Workbench 3.3

C/C++ Team Update 4.3 2/17/2010

Note: this software will work with either the V19 or V20 cRIO image to be installed.

This update is just a rebuild of the 4.2 update to resolve issues with camera and image processing symbols not showing up in the library. There are no functional changes since the previous update.

Workbench Software update download

C/C++ Team Update 4.2 2/8/2010

Note: this software requires the V19 cRIO image to be installed to operate properly!

This update fixes a compiler problem that was causing the kLineLength symbol in the DriverStationLCD class to show up as undefined. This is the only change since the previous update so if you weren't using the DriverStationLCD class there is no reason to install it.

Workbench Software update download

C/C++ Team Update 4.1 2/3/2010

Note: this software requires the V19 cRIO image to be installed to operate properly!

There have been several changes from Version 4.0 to 4.1. Most are source-code compatible meaning that you won’t have to change any of the code that you have written. One change may require you to make changes to your source code.

• Improved camera support. The AxisCamera class now is much more robust and should be much more resilient to different ordering of powering on the cRIO and the camera. Also it will be less likely to cause problems in the case of a intermittent power failure.
• The camera code now is much more efficient with less copies and image buffer allocations in the library.
• The PC Video server (images back to the dashboard) are much faster now – it should in most cases run at the full camera rate. For image sizes of 320x240 the total lag should be around 0.5 seconds. Smaller images are lower.
• The kit I2C accelerometer is now supported in the ADXL345 class.
• Note: the Axis Camera and Image class methods have been renamed to have upper case first character names with camel case for the rest of the name. The names are the same as before, but now everything is consistently using the same naming convention. This will be a one-time change and should be pretty easy to implement in any code using the vision classes.
• Many I2C cleanups in the code.
• The default gyro sensitivity now matches the 2010 kit gyro. You can still explicitly set the sensitivity in V/deg/sec using the Gyro.SetSensitivity method on the gyro class.
• Several other bug fixes and improvements throughout the library.

Getting Started with C++ (pdf) download

Workbench Software Update download

C/C++ Team Update 4.0 1/9/2010

Note: this software currently requires the V19 cRIO image to be installed to operate properly!

• WPILib User's Guide (pdf) download
• Getting Started With C++ (pdf) download
• Workbench Software Update download
• The mandatory LabVIEW update contains the new images and imaging tool to work with Java or C++.
• Source code for WPILib (zip) download
• NetConsole Software download

  • The NetConsole tool provides a way to capture console input and output and send it over the network to a client on your
    development computer. There are two parts to the NetConsole, a client and a server. The server is installed
    on the cRIO, but not enabled by default in the C++ version of the image. To enable it, add 'NetConsole.out;' to the
    beginning of the EarlyStartupLibraries token in the ni-rt.ini file.

    Open up the client on a machine with the LV Runtime Engine installed and on the same subnet as the robot (anywhere the
    imaging tool runs). Keep the data directory with the executable. When it loads, you'll see an IP address field at the
    top that is blank.

    When you reboot your chassis, the broadcast UDP packets sent from the server will be received by the client. At this
    point the IP address will be populated and the client can now send your keystrokes back to the server. Also, if you
    have more than one server on the subnet, the client will only pay attention to packets from the IP listed at the top.
    Click the Auto button to reset the IP to empty and wait for more broadcast packets.

    If you want to send commands to an already booted chassis and you don't want to reboot, you can just type in the
    controller's address and start sending it commands.

C Team Update 3.1 2/25/2009

C/C++ Update 3.1.

This update has a number of bug fixes and improvements. This requires the latest cRIO update FRC_2009_v11.zip (same as previous C/C++ update below).

While we believe this code is well tested, it is impossible to know for sure how it will behave on your robot. Because robots have shipped and there may be no way of testing this update adequately on your robot until you are at a competition, please be sure to have a copy of the previous update that you can reinstall in case you have unexpected results. With that said, here are the changes:

1. Many documentation updates
2. Updates to PIDController class to fix bug with continuous option and added a semaphore for syncronization between task and main code. Also fixed an issue with Notifier running continuously. Added setters and getters for P, I, and D coefficients.
3. Camera rotation is restricted to 0 or 180 degrees.
4. Fixed a number of issues with the Notifier class causing it to not be deleted properly.
5. Modified parameter names in various places to match between the header and source files.
6. Fixed problem with DeleteSingletons()
7. Fixed issue with synchronization objects caused by incorrect Semaphore creation. This should eliminate some eratic behavior in a number of classes include Analog sampling where multiple tasks are running at the same time.
8. Counters will now return infinity when the timer in the counter detects a stalled condition. Be sure to set the MaxPeriod in any cases where this might affect program operation.
9. A number of other issues with Notifiers as described here: http://forums.usfirst.org/showthread.php?t=12020
10. Added a void * parameter to DigitalInput RequestInterrupts to allow passing context to an interrupt service routine.
11. Set default MaxPeriod in the Ultrasonic object to allow it to not timeout between pings.

Downloads

• Workbench Updater: WorkbenchUpdate_3.1.1764.exe (19.7Mb) - remember to keep a copy of the previous update (3.0.1718) if testing at an event.
• Source code for version 3.1.1764 (360Kb)
• Documentation - also located in C:WindriverdocsexternsionsFRC (34Mb)

C Team Update 3 1/27/2009

C/C++ Update 3.0.1718

This update adds the following fixes and updates. This update requires the latest cRIO update FRC_2009_v11.zip. It will not work without applying this update.

1. Removed the Encoder::SetReverseDirection() method. The reverse direction flag is on each of the Encoder constructors as an argument.

2. Added 1X and 2X decoding to the Encoder class to allocate counters instead of the 4 Encoder FPGA objects.

3. Fixed a bug in the TrackAPI code where FindColor was returning the first particle rather than the largest particle.

4. Fixed a bug in TrackAPI.InArea where positions were incorrectly identified

5. Added CameraDemo sample program for camera configuration

6. Updated TwoColorDemo to use fix in library for InArea

7. Added camera property set and get methods to AxisCamera.cpp

8. Added configuration file processing to BaeUtilities.cpp

9. Modified Encoder::Get() method to return a normalized result (1x, 2x, and 4x will return same result)
10. Fixed the default Watchdog timer value to be seconds rather than milliseconds

Downloads

• Workbench Updater: WorkbenchUpdate 3.0.1718.exe (19Mb)
• Source code for vRC0.1718: WPILibRC0.1718SourceCode.zip (372kb)
  (remember that this will only work with the FRC_2009_v11.zip cRIO image, below or with LabVIEW update)
• cRIO Image updater (stand-alone without LabVIEW) - FRCNIWRUpdate3.0.a.zip (90.5 Mb)
• Documentation - also located in c:windriverdocsextensionsFRC after the installation - FRC1718Docs.zip (17 Mb)
  • C++ Reference as a Windows Help file with hyperlinked class diagrams
  • C++ PDF Reference document
  • C PDF Reference document
  • FRC Vision Windows Help File
  • FRC Vision API Specification

Sample Vision Target Tracking Program (now contained in C Team Update 3)

This program is a sample program that implements two color tracking in the autonomous mode. It assumes that you are using a gimbal such as the one provided in the 2009 kit, with two servos on PWM 9 and 10.

This program follows a pink/green target during the Autonomous period. It looks for green above pink. To change to pink above green, modify the input parameter from ABOVE to BELOW. Determination of alliance (pink/green order) is left as an exercise for teams, either by mechanical means or input from the Driver Station.

This demo assumes that the camera is set up as follows: White balance: Fluorescent 1, Auto Exposure on, Brightness: 40. We had good results with the code testing in a range of lighting conditions from dim fluorescent to bright stage lighting (similar to a competition). If you are having trouble getting the program to recognize the target in some specific lighting condition, be sure to look at an image with these settings to make sure the target is not washed out (all white) or too dark. The auto exposure will tend to find a single setting based on everything in the image including dark and brightly lit backgrounds. This may tend to throw off the exposure for the target in the forground.

Download (44k) - TwoColorTrackDemo-v2.zip (Note: updated Thursday, Jan15, 2009 4:10PM EST)

Update Version 1.2 (build 1562) 1/1/2009

Wind River Workbench User's Guide

This update is cummulative - you do not need to install previous updates before this one, it can be installed either after a fresh install of the team DVDs or after Temporary update 1 (below). This update adds or fixes the following:

1. All times have changed from whatever units they were previously in to float or double seconds. Methods in previously written code for functions like Wait() or returned periods from counters and encoders, and the Timer class, etc. need to be changed.
2. Added header for GetImageData() in AxisCamera.h
3. Added PanInit() and PanForTarget to BaeUtilities.cpp to support servo panning.
4. Changed the RobotDrive class and supporting C functions to use Jaguars instead of Victors.
5. Fixed some bugs in Timer and Ultrasonic classes.
6. Added method to Encoder to reverse direction sensing for encoders mounted in opposite direction.
7. C Interfaces are now implemented for most functions. There are still some of the more complex functions that are currently only accessible in C++ like AnalogTriggers.
8. Added missing methods to Joystick object.
9. Added demo for viewing images from the camera on the LabVIEW dashboard program.
10. Added PCVideoServer class to send images to the dashboard. To use this, the camera must be initialized.
11. Added Task class for creating and manipulating tasks in C/C++ programs. Tasks created with these objects will automatically be deleted when the parent object is deleted.
12. Added DashBoard class for creating the robot-side of dashboard programs in C/C++ to send data back to the LabVIEW dashboard program.
13. Added DashBoard example program showing the method of packing data to send it to the dashbaord application. Also includes a class that can pack in the format of the default DashBoard application.
14. Modified the ArcadeDrive code in the RobotDrive object (and corresponding C functions) to use an algorithm that prevents overflow when joysticks are set to full X and Y (full 45 degree angle). Also optionally will modify the inputs to be more sensitive for low speed driving. This is compatible with the LabVIEW version of WPILib.
15. Improved the PIDController class to include a user settable loop time parameter especially useful for integral and proportional control.
16. New documents including a PDF version of the C++ Reference Manual, the C Reference Manual, and updated version of the C/C++ Users Guide.
17. Sample programs have been renamed to be more descriptive and understandable.

Download (requires new cRIO image - see below):

• WorkbenchUpdateV1.2.1562.exe (8.2mb) - both Labview and C++ usersmust
  1. download the LabVIEW upadate, FRCLabVIEWUpdate2.0.zip from NI,
  2. Run it, then
  3. Run the Labview CRIO imaging tool to update their CRIO (with the new FRC_2009_V7.ZIP image file).
  This update will not work completely without making this cRIO image update.
• Documentation:
  • C++ Reference Manual (doxygen generated)
  • C Reference Manual (doxygen generated)
  • NIVisionCVI help file


• Source code for build 1562.

We will soon have a SourceForge server running and we'll post messages when that is running. In the mean time, please don't try to sign up for the WPI Campus SourceForge server. We'll let you know when the FIRST project server is going.

For those not installing LabVIEW, the new image and installer can be installed by using this update (90mb). Remember, the new cRIO image is required for this version of WPILib.

Temporary update 1 (12/10/2008)

You must install this update after the reflashing the cRIO with the image contained in FRCLabVIEWUpdate1.0. This is a temporary update that will be replaced shortly with the final version 1 C/C++ update. Check back in a few days for the version 1 update.

Download: Worlds easyest game answers.

• Beta update 5 (16mb)
• Source code for beta release

This code will be replaced shortly with a more complete version (see notes below).

C/C++ Programmer Reference Guide (generated from doxygen) - reference guide for all the classes and methods in the library. C and Vision will be updated shortly.

C/C++ Users Guide - describes the use of the library, using Wind River Workbench, and general tips and techniques. Also updating.

Mandatory cRIO Image Updater (you must update the cRIO image before using the above Beta Update 5. It can either be done with the following imaging tool or by using the imaging tool installed with the LabVIEW update FRCLabVIEWUpdate1.0)

Download: FRCNIWRUpdate1.0 (88mb) - do not use this updater for V1.2 or newer of the C/C++ libraries!

Notes about the update

• The following C++ classes should not be used:
  • Task
• C wrappers are only partially implemented and will be complete in the next update.
• Times in functions like Wait and in periods for encoders, counters, ultrasonic, etc. will be changing to floating point seconds for units rather than milliseconds and microseconds.
• Documentation will install in the C:WindRiverdocsextensionsFRC
• To use the C/C++ update you must reflash the cRIO image to version 1.0 from the above imaging tool or from the LabVIEW Update 1.0

FIRST Robotics Resource Center - Worcester Polytechnic Institute

100 Institute Road, Worcester, MA 01609-2280 Phone: +1-508-831-6796 Fax: +1-508-831-5680 firstresources@wpi.edu

You are now ready to build the operating system and applications that will run on your Gateway. You have two choices to build your OS. Each will take several hours to complete:

• Using a Command Line.
• Using Wind River Workbench.

The following options require an Intel^® IoT Gateway Pro Software Suite license to use or deploy on a Gateway. A license is available at the Intel^® IoT Platform Marketplace:

• wr-exegin-zigbee-ia

• wr-prosyst-mbs-smarthome-sdk-ia

• wr-wks-oneagent-oma-dm-ia

• wr-wks-oneagent-tr069

• wr-ma

• wr-mcafee

These options are referenced in step 2 when using a command line, and in step 20 when using the Wind River Workbench.

Using a Command Line

These steps use an example Wind River Linux configure command with options that vary slightly by Gateway model. To see additional options, see the Wind River^® Intelligent Device Platform XT Programmer’s Guide.

1. Go to the $HOME/Project directory on your Development Computer:

2. Define your Gateway options by copying and pasting the configure command to the Development Computer. In addition to the configure options listed here, you will potentially include other packages that contain drivers for your specific gateway hardware and layers for your gateway application software.

   Tip:To copy and paste this code or command, hold your mouse over it and look for this icon:

   Important: The parameters vary by Gateway processor. Use the configure command for your Gateway processor:
   • Configure for Intel^® Atom™ processor
   • Configure for Intel^® Core™ processor
   • Configure for Intel^® Quark™ processor

   The configure command will take several minutes to complete. Upon completion, your terminal prompt will return.

3. Build the Gateway operating system:

   The Gateway OS build takes 3 - 5 hours and creates files with *.bz extensions in $HOME/Project/export.

4. The config.log created in $HOME/Project is an exact copy of the configure options used to build the Gateway OS. Save this as config.sh for future development projects:
5. Continue to Copying the Gateway OS to a USB Flash Drive.

Using Wind River Workbench

1. Launch Wind River Workbench:
2. In the Workspace Launcher window select a workspace folder and then click OK. For example: home/<username>/WindRiver/workbench-4/workspace where <username> is your Linux login ID.
3. From the main menu, click File > New > Wind River Workbench Project.
4. Select Platform as the build type. Click Next.
5. Type a name for your project. Click Finish.
6. Click Add Option.
7. Locate and highlight --enable-addons=[ ]. With the line highlighted, replace the text in the Option: field with --enable-addons=wr-idp. Click OK.
8. Click Add Option again.
9. Locate and highlight --enable-internet-download=..
10. With the line selected, replace the entire Option field with --enable-internet-download=yes
11. Click OK.
12. Click Add Option again.
13. Locate and highlight --with-package=.. With the line selected, replace the entire Option field with the following.
    Tip:To copy and paste this code or command, hold your mouse over it and look for this icon:


    Click OK.

14. IMPORTANT: Click Rescan Layers.
    Refer to the following figure to complete the next steps:
15. The Board option refers to the processor type installed in the Gateway. Select the correct Board for your Gateway:
    • Intel^® Atom™ processor: select intel-baytrail-64.
    • Intel^® Core™ processor: select intel-haswell-64.
    • Intel^® Quark™ processor: select intel-quark.
16. Select idp for both RootFS and Kernel.
    Important: If idp is not listed as a choice, repeat steps 6 - 15, making sure you correctly define --enable-addons=wr-idp in step 7 and Rescan Layers in step 14.

    Keep referring to the figure above for steps 17 - 21.

17. Click Add Layer.
18. Click Browse.
19. In the Places window select your user name (your home directory), and then the folder WindRiver/wrlinux-7/addons/wr-idp/layers/sys-version. Click OK, and then click Add.

20. Repeat steps 17 - 18 to add these layers:

    Important:

    The parameters vary by Gateway processor. Use the correct layer list for your Gateway processor:

    • Intel^® Atom™ or Core™ processor
      • wr-hac-agent
      • wr-kernel/kernel-dev
      • wr-ma
      • wr-mcafee
      • wr-prosyst-mbs-smarthome-sdk-ia
      • wr-wks-oneagent-oma-dm-ia
      • wr-wks-oneagent-tr069
    • Intel^® Quark™ processor
      • wr-exegin-zigbee-ia
      • wr-hac-agent
      • wr-kernel/kernel-dev
      • wr-ma
      • wr-mcafee
      • wr-prosyst-mbs-smarthome-sdk-ia
      • wr-wks-oneagent-oma-dm-ia
      • wr-wks-oneagent-tr069
21. Click Add Template.
22. Locate and select the following features. Select them by clicking the box at the left of each. Refer to the figure below the list of features.
    Important: The parameters vary by Gateway processor. Use the correct parameter list for your Gateway processor:
    • Intel^® Atom™ or Core™ processor
      • feature/backports
      • feature/bluetooth
      • feature/haccmds
      • feature/ipsec_vpn
      • feature/non-grsec
      • feature/online_updates
      • feature/openjdk-bin
      • feature/pptp_vpn
      • feature/recovery
      • feature/self-hosted
      • feature/target-toolchain
      • feature/vlan
    • Intel^® Quark™ processor
      • feature/backports
      • feature/bluetooth
      • feature/haccmds
      • feature/ipsec_vpn
      • feature/non-grsec
      • feature/odm/aiot-x1000
      • feature/odm/cse-e100
      • feature/odm/ecs-gen2
      • feature/odm/kbox-a201
      • feature/odm/reliagate
      • feature/online_updates
      • feature/openjdk-bin
      • feature/pptp_vpn
      • feature/recovery
      • feature/self-hosted
      • feature/target-toolchain
      • feature/vlan
23. Click Done.
24. Click Run Configure.

    The configuration runs for a few minutes, and then displays results.

25. Click Finish.
26. From the Workbench menu, select Project > Build Project.
27. Click OK in response to the message about parallel builds.

    The operating system build begins. It will take 3 - 5 hours to complete. A file with a .bz2 extension and a config.log file are created in $HOME/Project/export.

28. Save config.log as config.sh for future development tasks:
29. Continue to Copying the Gateway OS to a USB Flash Drive.
