Summary of Contents for Timex T100

• Page 1 T100 USER MANUAL..
• Page 2 For Repair or Service Time Clocks Division of Acroprint 5640 Departure Drive Raleigh, NC 27616-1841 In USA 800-283-0594 www.timextimeclocks.com is a registered trademark of TIMEX Corporation. Manufactured under license.

• Page 3: Table Of Contents

  Setting Signal Duration ..15 Changing the Default Password ..16 Exiting Program Mode ..16 Operating the T100..17 Punching Time Card..17 VII. Installing the T100: Wall-Mounting ..18 VIII. Maintenance ..20 Replacing the Ribbon ..20 Troubleshooting ..21 Location of Fuses ..22 Error Codes..22 Warranty..23..

• Page 4: Introduction

  Overview The Timex T100 is an electronic time clock that can be used for a weekly or a bi-weekly pay period. The unique Timex T111 Time Card offers a weekly time card on the front and a biweekly time card on the back. IN/OUT punches are recorded across the card in six columns by using the buttons to select the appropriate column.

• Page 5: Features

  Ambient Humidity: 20%～80% Size: 8.0'W × 10.5'H × 5.6'D (203mm W × 267mm H × 142mm D) Accessories: The T112 Ribbon and T111 Time Card are made specifically to work in the T100 Time Clock. T112 Two-Color Ribbon T111 Weekly/Bi-Weekly Time Card..

• Page 6: Package Contents

  II. Package Contents User Wall Mounting T100 Manual Bracket T100 User Manual Wall Transformer Screw & Anchor (2) Keys 4 pcs Each M4x10 Screw Wall Mounting 2 pcs Template..

• Page 7: Location Of Components

  III. Location of Components Front Front Time Card Receiver Key Hole <AM IN> Button <AM OUT> Button <PM IN> Button <PM OUT> Button <OT IN> Button <OT OUT> Button Digital Clock Display Back 10) Program/Normal Mode Switch 11) Reset “A” (return to original factory settings) 12) Wall-mounting Keyholes 13) Fuse Access Door Back..

• Page 8: Quick Setting The T100

  Time Zone – Eastern Standard Time Pay Period – Weekly Daylight Savings – Automatic There are many additional options with the T100 outlined on Page 6. Note: If you desire any of these options, proceed to the appropriate section for programming.

• Page 9: Setting The T100

  12. Set signal tone duration time (Default: 5 seconds) 13. Change default password (Default: 1234, change as desired) Exit programming mode If you do not need to change any of the default settings you may proceed to “Operating the T100” on page 17.

• Page 10: Programming Hints

  Programming Hints Leaving the T100 plugged in overnight will typically set the time and date automatically utilizing the Atomic Synchronization Signal. Once the time and date are set simply skip over these features when setting the T100. It is recommended that you program all functions in one sequence. However, you may set functions independently by following the directions in parenthesis that refer “to just entering the program mode”..

• Page 11: Setting Pay Period And Current Print Line

  1. Setting Pay Period and Current Print Line The T100 can be programmed for weekly or bi-weekly pay periods. To Set Weekly Pay Periods • Press <OT IN> to advance the current day of week. The “2” indicates a weekly pay period.

• Page 12: Setting The Time

  • Press <OT OUT> to save. 3. Setting Year, Month, and Date Atomic Synchronization by leaving T100 plugged in overnight. Once the “Atomic Signal Synchronization Indicator” is on the date is set.) • Press <AM IN> once to set the year, month and date times if just entering the programming mode) •..

• Page 13: Setting The Minute Printing Format

  5. Setting the Minute Printing Format The T100 will print in standard minutes (60) or in decimal hundredths (100) of an hour. Decimal hundredths allow time calculations without having to convert minutes to decimal hours. standard minute format or as 12.75 if hundredths is chosen.

• Page 14: Daylight Saving Time (dst)

  The DST setting (2007 forward) is as follows: The starting time is 2:00 AM on the second Sunday in March. The ending time is 2:00 AM on the first Sunday in November. The Atomic Synchronization will adjust the T100 automatically for Daylight Saving Time.

• Page 15: Setting Two-color Printing

  10. Setting Two-Color Printing Time cards can be audited more easily by highlighting punches outside the normal work schedule in Red. The T100 allows 18 red/black color changes. If you set a color change it will occur every day. Note: The default color is black. The clock has to be programmed to print red at specific times.
• Page 16 Press <OT IN> to advance the minute of the event. • Press <OT OUT> to save and advance to the next scheduled event (example “02 12:00”). • Repeat as necessary until all desired events are set. Use the following chart to create a schedule to assist in programming Two-Color Printing.

• Page 17: Setting The Signal Tone Times

  11. Setting the Signal Tone Times The T100 allows for 32 scheduled audible signals. If you set a signal it will occur every day and sound for the set signal duration. Following is a sample schedule of events for an 8:00 AM to 5:00 PM work schedule with one hour lunch from 12:00 Noon to 1:00 PM (13:00).

• Page 18: Setting Signal Duration

  Use this chart to create a schedule to assist in programming Signal Tones. 12. Setting Signal Duration The T100 can produce a signal for 0 to 30 seconds (Default is 5 seconds). • Press <AM IN> once programming mode begin at “Inputting the Default Password”..

• Page 19: Changing The Default Password

  Press <OT OUT> to save the password. Important: Write the new password here Once the password has been set the T100 will display “0000” each time you enter the programming mode. The password must be entered and <OT OUT> pressed to enter program mode. If the password is incorrect, the T100 will beep and Error Message “E-40”..

• Page 20: Operating The T100

  The print on the time card progresses to the right through out the day as the IN/OUT buttons are pressed. The T100 prints in the column of the time card indicated on the lower line of the Time Clock Display. The column is selected..

• Page 21: Installing The T100: Wall-mounting

  VII. Installing the T100 The T100 may be installed on a flat surface or wall-mounted. No special wiring is needed. However, we recommend installing the T100 on a separate power circuit. We do not recommend using a power strip. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.
• Page 22 Line up the keyholes on the back of the T100 with the mounting screws. Slide the T100 downward to secure it to the wall. Secure mounting bracket to wall with screw (included) or mark hole and install screw anchor (included) if..

• Page 23: Maintenance

  It is not necessary to replace the pin and clip. Place the new ribbon into the T100. Check to be sure the ribbon is still tight. Close the front cover. Pin &..

• Page 24: Troubleshooting

  Clock does not AC power is OFF accept time Power cord is cards disconnected AC fuse blown DC fuse blown T100 in “Program” mode Printing light Worn ribbon Ribbon cassette not seated correctly Printing in Incorrect pay period wrong position..

• Page 25: Location Of Fuses

  Location of fuses The fuse panel is located on the back of the T100 in the lower left corner. To access fuses, disconnect the power from the clock and remove the screw that secures door. Replace blown fuse with only the same rated fuse. Do substitute.

• Page 26: Warranty

  Cycling the power to the T100 may also correct certain error conditions. If any of these measures fail to correct the error condition, contact the dealer or Service Center at: 1-800-283-0594 or go to: www.timextimeclocks.com To return to the original factory settings press the <RESET> button with the end of a pen with the programming switch in “NORMAL”..

• Page 27: Product Registration Card

  Product Registration Card Fax to 919.850.0720 or Drop in envelope to: 5640 Departure Dr. Raleigh, NC 27616 T100 Model No. First Name Title Company Name Address City Daytime Phone with Area Code Purchased From So that we may serve you better, please indicate your primary business activity.
• Page 28 Time Clocks Division of Acroprint 5640 Departure Drive Raleigh, NC 27616-1841 In USA 800-283-0594 www.timextimeclocks.com is a registered trademark of TIMEX Corporation. Manufactured under license. P/N 06-0337-000 Rev. C..
